Post fitting round shape for external thread and tube ∅ 33,7 mm

제품 라인업 — Frames · Post fittings

Post fitting round shape  for external thread and tube ∅ 33,7 mm
No. a α lx ø d1 ø d2 ø d3 kg
30862-0501-33 M5 0° 3 10 5.5 33.7 0.0030
30862-0601-33 M6 0° 4 13 7.3 33.7 0.0060
30862-0801-33 M8 0° 4 18 8.5 33.7 0.0140

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
